Description
xEaton Wiring Devices Duplex Receptacle Wallplate, 125 V, 15 A, Frequency Rating: 60 Hz, Number of Poles: 2, Number of Wires: 3, Wiring Type: Back, Side, Wire Size: 14 to 10 AWG, NEMA Configuration: 5-15R, Operating Temperature: 30 deg C, PVC/Thermoplastic, Ivory, Dimensions: 2.81 in L x 2.01 in W x 4.62 in H, Includes: Thermoplastic Wallplate
Protects from both series and parallel arcs downstream from the outlet Branch Circuit (OBC) AF/GF receptacle
OBC AF/GF receptacles also protect from upstream series arcs
Trip indicators make it easy-to diagnose arc and ground faults
Device self-tests periodically to ensure proper function of both the ground fault and arc fault protection elements
Meets and exceeds 10 kA short-circuit testing and underwriters laboratories (UL) UL943 safety standards
Ground termination with back wire clamp provides secure wiring and reduces installation time
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
Tapered back wire openings handle multiple wire sizes and types for applications up to #10 AWG solid or standard wire
When downstream receptacles are wired from load side, a 20 A feed-through rating offers full protection
